ASTM BS All Aluminium Alloy Conductor Overhead Transmission

Brand Name : Sanwu

Model Number : AAAC

Certification : TUV

Place of Origin : Henan

MOQ : 1000M

Price : Negotiate

Supply Ability : 200 tons per day

Delivery Time : 1-15days

Packaging Details : Non returnable wooden / steel reels

Name : All Aluminium Alloy Conductor

Application : Overhead Transmission

Rates : 0.6/1kv

Standard : ASTM BS

Type : LV

Contact Now

China Cable 1/0 AWG Bare All Aluminium Alloy Conductor 7/3.37 mm Diameter with AAAC Conductor

The bare conductor:AAC,AAAC,ACSR,AACSR,ACAR and Galvanized steel wire, are used in overhead electrical power transmission and distribution lines with various grade voltage.

Standards:

All aluminium conductor(AAC bare conductor) meets or exceeds the following ASTM standards:

(1)B-230 Aluminium wire,1350-H19 for electrical purpose

(2)B-231 Aluminium conductors,Concentric-Lay-Stranded

(Also meet BS215-1 and DIN48201 Standards)

All aluminium alloy conductor(AAAC-6201 bare conductor meets or exceeds the following ASTM standards:

(1)B-398 Aluminum-alloy 6201-T81 wire for electrical purposes

(2)B-399 Concentric-Lay-Stranded 3201-T81 aluminium alloy conductors

(Also meet BS3242 and DIN48201 Standards)

Construction:

Aluminium 1350-h19 wires,concentrically stranded. (AAC conductor)

Aluminium alloy 6201 wires,concentrically stranded. (AAAC conductor)

The technical parameter

Code Number Stranding&wire diameter Approx Overall diameter Nominal Approx. Breaking Load DC Resistance at 20
area Weight
mm mm mm 2 Kg/km KN Ohm/km
16 7/1.83 5.49 18.4 50.4 5.43 1.7896
25 7/2.29 6.86 28.8 78.7 8.49 1.1453
40 7/2.89 8.68 46 125.9 13.58 0.7158
63 7/3.63 10.9 72.5 198.3 21.39 0.4545
100 19/2.78 13.9 115 316.3 33.95 0.2877
125 19/3.10 15.5 144 395.4 42.44 0.2302
160 19/3.51 17.6 184 506.1 54.32 0.1798
200 19/3.93 19.6 230 632.7 67.91 0.1439
250 19/4.39 22 288 790.8 84.88 0.1151
315 37/3.53 24.7 363 998.9 106.95 0.0916
400 37/3.98 27.9 460 1268.4 135.81 0.0721
450 37/4.22 29.6 518 1426.9 152.79 0.0641
500 37/4.45 31.2 575 1585.5 169.76 0.0577
560 61/3.67 33 645 1778.4 190.14 0.0516
630 61/3.89 35 725 2000.7 213.9 0.0458
710 61/4.13 37.2 817 2254.8 241.07 0.0407
800 61/4.38 39.5 921 2540.6 271.62 0.0361
900 91/3.81 41.8 1036 2861.1 305.58 0.0321
1000 91/4.01 44.1 1151 3179 339.53 0.0289
1120 91/4.25 46.7 1289 3560.5 380.27 0.0258
1250 91/4.49 49.4 1439 3973.7 424.41 0.0231

ASTM BS All Aluminium Alloy Conductor Overhead TransmissionASTM BS All Aluminium Alloy Conductor Overhead Transmission

ASTM BS All Aluminium Alloy Conductor Overhead Transmission

Luoyang Sanwu Cable Co., Ltd., with registered capital of 100 million RMB, is a high-tech development company for scientific research, industry producing and trading , offering a diverse selection of quality wires and cables to industrial customers in 33 countries worldwide. The leading products are ACSR, overhead conductor, AAAC, AAC, power cable, BLXY, home-used wire and so on.
Sanwu cable owns variously advanced equipment and large quantities of high skilled professionals. With complete management system, advanced production process, strict testing procedure and reliable product quality, we have successively got IS09001, IS014001,OHSAS18001,TUV Certificate, CCC(China Compulsory Certification), the national industrial production license and so on.
In terms of quality, It is highly controlled by our company to ensure that all the products we sell meet your requirements and give you reassurance with excellent after-sale service.In terms of service, we are focusing on your need, we concern what you concern and request what you request to provide a more satisfied service.

ASTM BS All Aluminium Alloy Conductor Overhead Transmission

FAQ:

Q: Are you trading company or manufacturer ?
A: We have our own factory and trading company, our factory have more than 10 years production experience.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, and it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.L/C is also available.

Q:Have you ever supplied cables to our country ?

A: Cables have been supplied to many countries across the world such as USA, Australia, Switzerland, Singapore, Sri Lanka, the Philippines, Mongolia, UAE, Yemen, Iran, Iraq, Nigeria, Egypt, Lesotho, Cameroon, etc.
